General Specifications(详细说明)：
Winding Type………………………………………………… Star
Temperature Rise…………………………………………120℃ electrical angle
Insulation Class…………………………………………B
Ambient Temperature Range…………………………-20℃~+50℃
Insulation Resistance………………………100MΩMin.500VC DC
Dielectric Strength………………………………700V AC 1 minute
Electrical Specifications(技术数据): 型号Model | 60BL50-240-57XG | 60BL70-240-57XG | 60BL90-440-57XG | 60BL110-440-57XG | 60BL110-640-57XG | 极数Number of Poles | 8 | 相数Number of Phases | 3 | 额定电压 Nominal voltage VDC | 24 | 24 | 48 | 48 | 310 | 额定转速 Rated speed RPM | 3000 | 额定扭矩 Rated Torque N-m | 0.32 | 0.64 | 0.96 | 1.28 | 1.28 | 额定电流 RatedCurrent Amps | 5.5 | 11 | 8.3 | 11 | 1.7 | 输出功率 OutputPower Watts | 100 | 200 | 300 | 400 | 400 | 峰值扭矩Peak Tourque N-m | 1.0 | 1.92 | 2.88 | 3.84 | 3.84 | 峰值电流Peak Current Amps | 16.5 | 33 | 33 | 33 | 5.1 | 力矩常数Torqueconstant N-m/A | 0.06 | 0.06 | 0.09 | 0.12 | 0.76 | 反电势常数 BackEMF V/kRPM | 4.2 | 4.2 | 6.4 | 8.4 | 55 | 转动惯量 Rotor inertia kg·cm2 | 0.24 | 0.48 | 0.72 | 0.96 | 0.96 | 电机长度Body Length (L) mm | 78 | 99 | 120 | 141 | 141 | 重量 Mass kg | 0.85 | 1.25 | 1.65 | 2.05 | 2.05 | 减速箱比速Reducer speed ratio | 一级1:3.6 1:4.25 1:5.33 二级1:12.9 1:18 1:22.6三级1:76.7 1:96.2 1:151.4 | 减速箱长度（L1））Reduction box length mm | 一级49mm二级63.5mm三级77mm | 减速箱重量Reduction box mass kg | 一级0.5kg二级0.8kg三级1.1kg |
警戒:峰值力矩仅作为参数参考,接近或在此条件下长期使用,将导致电机损坏Caution 1: Peak (Stall) Torque is provided for the purpose of performance calculations only. Operate near, or at, a stalled condition will result in motor damaged. 注意:以上仅为代表产品,电压，功率、转速可根据客户要求制作Note: We can also manufacture products according to customer's requirements.
|
